Product parameters:
| Product Type: | 3G Antenna | Input Impedance: | 50Ω |
| Frequency Range: | 880~960MHz,1900-2170MHz. | V.S.W.R.: | ≤1.5 |
| Gain: | 15dBi | Polarization: | Vertical |
| Connector: | CRC9 | Radiation: | omnidirectional |
| Cable Length: | 5m | Power: | 50W |
| Cable Type: | RG58/50-3 cable | Operating Temperature: | -45 to +75℃ |
| Weight: | 0.7kg | Storage Temperature: | -45 to +75℃ |
| Mounting: | Magnetic | Housing: | White |
Frequency Range(MHz)880~960MHz,1900-2170MHz.
GSM 900:880~960MHz
GSM 1900
UMTS 2100: 1900 - 2170 MHz
VSWR ≤1.5
Gain: 15dbi
Max Input power(W): 50
Input Impedance(Ω): 50
Polarization Type: Vertical
Radiation: omnidirectional
Cable Length(m): 5M
Cable Type RG58/50-3 cable
Connector Type : CRC9 or customized
SMA/SSMB/CRC9/TS9/MS147/FME//MC-Card..and so on.,
please give us notes if the connector is chosen !
Mounting: Magnetic
Housing: Black
Storage Temperature: -45'c to +75'c
Operating Temperature: -45'c to+75'c
The connectors / adapters we can offer you:
CRC9 connector/ adapter /Antenna for Huawei USB modem or other modem with CRC9
CRC9 connector/ adapter /Antenna for HUAWEI PCMCIA Card
CRC9 connector/ adapter /Antenna for HUAWEI Express Card
The connectors / adapters we can offer you:
CRC9 connector/ adapter /Antenna for Huawei USB modem or other modem with CRC9
CRC9 connector/ adapter /Antenna for HUAWEI PCMCIA Card
CRC9 connector/ adapter /Antenna for HUAWEI Express Card ,
