5.8GHz 3dBi Omni WIFI Antenna RP-SMA for wireless router Grey
Model: WA2-1321-S02SP1-030
Description
Product parameters:
| Product Type: | Wifi Antenna | Input impedance: | 50Ω |
| Frequency Range: | 5.8GHz | V.S.W.R.: | ≤2.0 |
| Gain: | 3 | Polarization: | Vertical |
| Connector: | RP-SMA male | Radiation: | omnidirectional |
| Weight: | 11g | Power: | 50W |
| Mounting: | Magnetic | Operating Temperature: | -45 to+85℃ |
This compact 5.8GHz omnidirectional "rubber-duck" WiFi antenna provides broad coverage and 3dBi gain. It is a coaxial sleeve design with an omni-directional pattern. It is ideally suited for IEEE 802.11a wireless LANs
This flexible antenna features a tilt-and-swivel SMA connector, allowing them to be used vertically, at a right angle, or any angle in-between. It is suitable as a replacement RF antenna for many access points and radios that are equipped with SMA connectors including D-LinkR, LinksysR WET11 and others.
for wireless router and WLAN PCI card
Diameter: 9mm
Length: 115mm
weight:11g
802.11a
RP-SMA male Connector
Flexible WiFi antenna
Tilt and swivel design
Color:Silver Grey
