2.5dbi GSM/UMTS/HSPA/CDMA/3G Modem Antenna for Devices/Wireless
Model: 3A1-2207-C01RA-025-300
Description
Product parameters:
| Product Type: | 3G Antenna | Input impedance: | 50Ω |
| Frequency Range: | 850-960/1710-2170mhz | V.S.W.R.: | ≤1.5 |
| Gain: | 2.5 dbi | Polarization: | Vertical |
| Connector: | CRC9 male | Radiation: | omnidirectional |
| Cable Length(M): | 3m | Power: | 60W |
| Cable Type: | RG174 | Operating Temperature: | -45 to +75℃ |
| Weight(kg): | 0.046kg | Storage Temperature: | -45to +75℃ |
| Mounting: | Screw | Housing: | Black |
